Overview:

The Skystars F7 HD Wifi flight controller and KO45 4in1 stack is the combination of two very high specification products in one easy to use stack. The Skystars F7 Wifi supports the DJI HD video system with a dedicated 10V output as well as traditional analogue video OSD. It features a high speed F7 processor and has 6 uarts for connecting peripherals. The F7 HD Wifi also features a wifi module that allows wireless in the field configuration via the SpeedyBee app.

The KO45 4in1 ESC supports 3-6S and includes high quality Mosfets, It runs BLHeli_32 firmware and supports all recent modern ESC protocols like DShot 1200 etc.

** Image shows the F7 HD FC but you will receive the FC HD wifi version (see second image for the correct flight controller one) **

KO45 4in1 ESC Specifications:

– Skystar KO45 ESC
– The installation size is 30.5mm x 30.5mm. The installation hole is M4.
– ESC weight: 12g
– ESC onboard current sensor.
– Continuous current: 45A
– Instantaneous current [5 seconds]: 55A
– Drive signal: Dshot300-1200 / Proshot1000 / Oneshot / Multishot / PWM
– MCU: STM32F051 Operation frequency: 48MHz
– Firmware: BLheli-32
– MOS tube model is QN3019M6

Skystars F7 HD Wifi FC Specifications
– MCU: STM32F722RGT6 216MHz 32BIT
– IMU: MPU6000 (SPI)
– Barometer: Yes
– OSD: Betaflight OSD & DJI HD OSD (UART6)
– 6 hardware UARTS (UART1,2,3,4,5,6,)
– Receiver: TBS/PPM/SBUS/IBUS/DSM
– ESC Telemetry: RX3
– Blackbox: 8MB
– ESC Soft: Dshot300/600/1200
– LED indicator: Blue for FC Status,Green 9V,Red 5V
– WIFI: SpeedyBee APP target name SKYSTARS F7
– Input voltage: 3-6S LiPo(11.1V~25V)
– LED Controller: 4 corner LED interface to support BF led
– RSSI Pad: YES
– Buzzer Pad: YES
– CURR Pad: YES
– Smartaudio: YES
– BEC 5V 2.5A & 10V 2.5A(Max 3A)
– Firmware: SKYSTARS F7HDPRO
– Dimensions: 38.5x40x6.2mm
– Mounting Holes: Standard 30.5mm square to center of holes
– Weight: 6.6g
Note:Since STM32F722 heat large , please leave at least 5mm interspace at both sides of the FC with nothing covered to make sure a good air circulation.
