ZOHD Delta Strike EDF Jet (PNP)

Overview

The ZOHD Delta Strike EDF Jet (PNP) is a unique and innovative FPV plane that features a 50mm electric ducted fan (EDF) propulsion system and a built-in 180° pan servo for your FPV camera. It is part of the ZOHD MKIII series of FPV wings that combine sleek design, high performance and immersive experience.

The ZOHD Delta Strike EDF Jet (PNP) is made of high-quality EPP material with a wingspan of 600mm and a length of 610mm. It weighs around 750g and can reach speeds of up to 120 km/h with a 4S LiPo battery. It comes with a 2611-4000KV motor, a 40A ESC with 5V/3A BEC and three 9g servos pre-installed. You only need to add your own receiver, battery and FPV gear to complete the plane.

The ZOHD Delta Strike EDF Jet (PNP) is designed to be easy to assemble, fly and land. It has a detachable main wing and tail fin that can be snapped together without glue. It has a clever air cooling design to protect your FPV gear from overheating. It has excellent flight characteristics, allowing you to glide smoothly in light wind conditions and perform agile maneuvers with precision. It also has a unique and charming “turbine” sound when flying that will make you feel like a real jet pilot.

This PNP edition includes pre-installed motor, ESC, Servos and hardware. Some assembly will still be required.

Features:
– World’s first 50mm EDF FPV Wing wl built-it pan servo
– Innovative designed airfoil and aerodynamic airframe
– Unique and charming“turbine” sound when flying
– With custom-designed servo bay on top of fuselage for a 180° Pan view
– ZOHD MKIII blended wing body configuration
– Clever air cooling design to protect your FPV gear
– Spacious room inside fuselage for batteries and FPV gear
– Detachable wings, tail fin and nose, portable and easy to pack
– EPP molded airframe, built in carbon fiber spar for enhancement
– Specially-designed servo arm“bunker’ structure will protect your servo arm from impacts and minimize drag
– Ball head buckle linkage for ailerons, high efficiency and more accurate
– Molded marks for“CG”under the wing
– Molded hand grip slots for a worry-free hand launch
– ”inside- the cockpit like” Immersive experience
– Looks AMAZING in the sky!

Specifications:
– Brand Name: ZOHD
– Item Name: Delta Strike
– Version: KIT, PNP (optional)
– Material: High-Quality EPP
– Wingspan: 600mm (23.66”)
– Length: 610mm (24.02”)
– Min. Speed: Around 30km/h
– MAX Flying Speed: 120 km/h (with recommended setup)
– Recommended Max Takeoff Weight: 750g

Power Combo:
– EDF: 50mm with 2611 4000KV motor
– ESC: 40A w/5v 3A BEC with XT60
– Servos: 9g *3PCS (1pc 180 Degree for Camera)

Includes:

1x ZOHD Delta Strike EDF Jet (PNP)

** Warranty Exclusion: Warranty on these models is D.O.A. only as the model is trivial to break and does not include any faults that develop during usage, crashes or otherwise. Once you receive the model please carefully test the model on the ground to ensure everything functions BEFORE your first flight as warranty will not be provided beyond that point. **
